Benz & BMW Diagnostic Tool Autel MaxiSys MS909
2022 Newest & Most Cost-Effective Diagnostic Tool
Autel MaxiSys MS909 Full Systems Diagnosis Services:
Doing regular and routine maintenance on a modern car is impossible without a diagnostic system. Even the simplest procedures require the participation of an auto scanner. That's why Autel engineers have been working on them and making them as user-friendly as possible in the new MaxiSys MS909. Now you can easily do functions like:
Oil Reset: Reset the oil change calculator in the engine and automatic transmission.
EPB: Replacement of brake pads on vehicles with an electric parking brake.
SAS: Adaptation of the sensor to the angular position of the steering wheel.
DPF: Regeneration of diesel particulate filter.
Brake Bleed: ABS Brake Bleeding.
IMMO: Disable any lost keys and add new keys. *ONLY for vehicles with low-grade anti-theft systems. Compatible with GM, Ford, Toyota, Honda, and other 56 brands or models.
TPMS: Battery registration and reset.
Seat Calibration: Calibrate the memory in replaced or repaired seats.
Airbag Reset: Resets the airbag data to clear the airbag collision fault indicator.
A/F Reset: Set or learn Air/Fuel ratio parameters.
Gearbox Reset: Help complete the gearbox self-learning to improve gear shifting quality.
Suspension Reset: Adjust the vehicle body height sensor for level calibration.
BMS: Battery registration and reset.
Autel MaxiSys MS909 Benz & BMW Diagnostic Tool
- The intelligent Repair Guidance tool
- ECU Programming Coding
- Repair Assist Tips, Bi-Directional Control.
Most advanced repair guidance and assist functions similar to Autel MS919 and Autel Maxisys Ultra
Compare with MaxiSys Ultra: Autel MaxiSys MS909 has the same repair assist functions as MaxiSys Ultra. In detail, MaxiSys MS909 doesn’t have the functions of View Multiple Functions At Once, 5-in-1 VCMI, or Dock Station, but MaxiSys Ultra has all. Except that, has all the functions as MaxiSys Ultra, it's a very nice choice for you.
Compare with MaxiSys MS919: MaxiSys MS919 has the 5-in-1 VCMI, but Autel MaxiSys MS909 doesn't have it, it has the same difference.
Autel MaxiSys MS909 has its MaxiFlash VCI which can wireless connection. So if you don’t need 5-in-1 VCMI, MaxiSys MS909 is your best choice, it has all the diagnose and repair assist functions.
Module Network Structure Topology: It can display all your car modules and connect each one with a line. From it, you can know which module has problems and if you can press that module, the device will display its DTCs, and enter them.
Repair Assistant: Repair Assist Software displays a list of recommended tests, the completion status, and priority for the undertaking. The higher the priority, the earlier the components should be tested.
Prioritization: The solution path is given in priority via automatic sorting.
Guided Maintenance: An integrated troubleshooting process organized into the operation steps, that guide the user to solve the maintenance problems.
Accurate recommendation: Automatically match the circuit diagram and pin position required for the fault.
Relevant Cases: The software automatically recommends repair processes that may be relevant to the vehicle and fault. These repair cases provide the technician with great insight when diagnosing and repairing.
Tech Bulletins: See official announcements issued by vehicle manufacturers regarding common problems including vehicle modules, DTCs, repair methods, program updates, and recall strategies. Currently available on Ford, GM, FCA, Toyota, Lexus, VW, Nissan, Honda, BMW, Mercedes, Audi, Hyundai, and Kia.
DTC Analysis: The DTC Analysis describes possible causes and solutions for vehicle faults. Currently available on GM, Ford, Toyota, Lexus, Nissan, Honda, VW, Audi, BMW, FCA, and Mercedes.
Module Network Structure Topology
With the structure topology of function, Autel MaxiSys MS909 can show all the vehicle modules with a color-coded topology communication structure network, all the faults of each module and the relationship between different modules can be viewed from it at a glance. You can press any module to display any DTCs and access that system.
DTC Analysis
On the Intelligent Diagnostics screen, the DTC Analysis contains repair assistance and information related to the fault codes, including the fault description, condition, fault influence, possible cause, and possible solution. The repair assistance information may vary by vehicle.
Repair Assist
The Repair Assist displays a list of items and their descriptions, completion status, and priorities. The higher the priority number is, the earlier the related items should be tested.
Autel MaxiSys MS909 Advanced Functions:
Autel MaxiSys MS909 ECU Programming ECU Coding--Autel diagnostic scanner MS909 comes with J2534 ECU programming device BMW Ethernet Cable(For F-Series Coding Programming), which is capable of replacing the existing software/firmware in the Electronic Control Units (ECU), programming new Benz/BMW ECUs and fixing software-controlled drivability issues and emission issues, update the computer software on the vehicle to the latest version.
Note: ECU Programming only for BMW/Mercedes Benz.
MaxiSYS MS909 Specifications:
| Operating System: |
Android 7.0 |
| Processor: |
Samsung Exynos8895V octa-core Processor (2.3GHz Quad-core Mongoose + 1.7GHz Quad-core A53) |
| Memory: |
4GB RAM & 128GB On-board Memory |
| Display: |
9.7 inch TFT-LCD with 1536 x 2048 resolution & capacitive touchscreen |
| Connectivity: |
• Wi-Fix2 (802.11 a/b/g/n/ac 2x2 MIMO) • BT v.2.1 + EDR • GPS • USB 2.0 (TWO USB HOST Type A, ONE USB mini device) • HDMI 2.0 • SD Card (Support up to 256GB) |
| Camera (rear): |
Rear: 16 Megapixel, Autofocus with Flashlight
Front: 5.0 Megapixel |
| Sensors; |
Gravity Accelerometer, Ambient Light Sensor (ALS) |
| Audio Input/Output: |
• Microphone • Single Speaker • 3-Band 3.5 mm stereo/standard headset jack |
| Power and Battery: |
15000mAh 3.8V lithium-polymer battery
Charging via 12V AC/DC power supply with the temperature between 0°C and 45°C |
| Input Voltage: |
12V/3A Adapter |
| Operating Temp.: |
0 to 50°C (32 to 122°F) |
| Storage Temp.: |
-20 to 60°C (-4 to 140°F) |
| Dimensions: |
304.4 mm (11.98") x 227.8 mm (8.97") x 42.5 mm (1.67") |
| Weight |
1.66kg (3.66lb.) |
| Protocols: |
DoIP, PLC J2497, ISO-15765, SAE-J1939, ISO-14229 UDS, SAE-J2411 Single Wire Can(GMLAN), ISO-11897-2, ISO-11897-3, SAE-J2819 (TP20), TP16, ISO-9141, ISO-14230, SAE-J2610 (Chrysler SCI), UART Echo Byte, SAE-J2809 (Honda Diag-H), SAE-J2740 (GM ALDL), SAE-J1567 (CCD BUS), Ford UBP, Nissan DDL UART with Clock, BMW DS2, BMW DS1, SAE J2819 (VAG KW81), KW82, SAE J1708, SAE-J1850 PWM (Ford SCP), SAE-J1850 VPW (GM Class2) |
MaxiSYS MS909 Package Content:
- 1x MS909 Main Unit
- 1x MaxiFlash VCI
- 1x Main Cable V2.0
- 1x USB 2.0 Cable V2
- 1x AC/DC Adapter(12V)
- 1x Cigarette Lighter
- 2x Light Fuse 6x30mm
- 1x Clipper Cable
- 1x Quick Reference Guide
- 1x Packing List
- 1x Soft Cloth
- 1x Carrying Case 504 x 133 x 360 mm
